Rifle · Obsolete
.35 Winchester
Winchester's early .35 caliber cartridge for the Model 1895 lever-action and single-shot rifles.
- Caliber
- 0.358″ · 9.093 mm
- Introduced
- 1903
- Case
- Rimless
- Primary use
- Hunting
- Status
- Discontinued
- Introduced
- 1903
- Type
- Rifle
- Origin
- United States
- Inventor
- Winchester
- Manufacturer
- Winchester Repeating Arms
- Standard
- Obsolete
- Status
- Discontinued
- Availability
- Collector
- Case capacity
- 55 gr H₂O
- Twist (typical)
- 1:12
- Primer
- Boxer Small Rifle
- Case type
- Rimless
- Max pressure
- 40,000 psi
- Eff. range
- 150 yd
- Recoil
- 22–30 ft·lb
Introduced by Winchester Repeating Arms
Ballistics
Published velocity/energy data isn't available for .35 Winchester — an obsolete/collector cartridge.
Performance
Dimensionscase measurements · scale drawing · size vs familiar rounds
Case dimensions — the scale drawing at the top of the page is built from these.
mixed/other · approximate| Measure | mm | in | ✓ |
|---|---|---|---|
| Bullet ⌀ | 9.09 | 0.358 | · |
| Neck ⌀ | 9.66 | 0.380 | · |
| Shoulder ⌀ | 10.59 | 0.417 | ~ |
| Shoulder angle | 13° | — | ~ |
| Base ⌀ | 11.58 | 0.456 | · |
| Rim ⌀ | 13.70 | 0.539 | · |
| Belt ⌀ | n/a | ||
| Rim thickness | 1.40 | 0.055 | · |
| Neck length | 8.61 | 0.339 | ≈ |
| Case length | 61.10 | 2.406 | · |
| Overall length | 80.31 | 3.162 | ~ |
Size vs familiar rounds
Drawn at true 1:1 — every case is accurate relative to the others. Absolute size depends on your screen's pixel density, so measuring one against a real ruler may be off. .35 Winchester is highlighted below.
Factory loads
Being verified
Advertised FPS, energy, and BC are withheld until loads clear verification.
Reloading costestimate cost per round vs factory
Estimate your cost per round and how it compares to factory. Inputs are yours — nothing is stored.
Cost estimate only — not load data. Charge weight is your input; follow published manuals for safe charges.
Firearms chambered in .35 Winchester
2 models in the database chamber .35 Winchester. Browse all →
Connected reference
History
Introduced by Winchester in 1903 for the Model 1895 lever-action and Model 1885 single-shot rifles. An early smokeless .35 caliber sporting round. Never achieved the popularity of .35 Remington and was discontinued relatively early in the 20th century.
FAQs
- What twist rate does .35 Winchester use?
- .35 Winchester typically uses a 1:12 twist rate.
- What bullet diameter is .35 Winchester?
- .35 Winchester uses a 0.358″ (9.093 mm) diameter bullet.
- Is .35 Winchester still in production?
- .35 Winchester is discontinued; typical availability is collector.
- What is .35 Winchester used for?
- .35 Winchester is primarily used for hunting.
Sources & provenance
Data & sources. Specs compiled from the Lindcott Armory reference; availability counted from 6 live factory loads; the trajectory is modeled (point-mass), not measured. See methodology. Spotted an error? Report it →
