Rifle · SAAMI
7mm Remington Ultra Magnum
Remington's rebated-rim 7mm unbelted magnum, introduced in 2001.
- Caliber
- 0.284″ · 7.214 mm
- Introduced
- 2001
- Case
- Rebated
- Parent
- .404 Jeffery
- Primary use
- Hunting, Long Range
- Status
- Active
- Introduced
- 2001
- Type
- Rifle
- Origin
- United States
- Inventor
- Remington
- Manufacturer
- Remington Arms
- Standard
- SAAMI
- Status
- Active
- Availability
- Limited
- Case capacity
- 103 gr H₂O
- Twist (typical)
- 1:9.5
- Primer
- Large Rifle Magnum
- Case type
- Rebated
- Max pressure
- 65,000 psi
- Eff. range
- 800 yd
- Max range
- 1500 yd
- Recoil
- 30–42 ft·lb
Introduced by Remington Arms
Ballistics
Real trajectory computed from a representative load — Nosler Trophy Grade 160 gr, 3,175 fps, BC 0.531 G1 · 100 yd zero · sight height 1.5 in.
| Range | Velocity | Energy | Drop (in) | Drop (MOA) |
|---|---|---|---|---|
| 0 yd | 3175 | 3581 | -1.5″ | — |
| 100 yd | 3076 | 3360 | 0.0″ | 0.0 |
| 200 yd | 2978 | 3150 | -2.2″ | -1.0 |
| 300 yd | 2881 | 2948 | -8.3″ | -2.6 |
| 400 yd | 2786 | 2757 | -18.6″ | -4.4 |
| 500 yd | 2692 | 2574 | -33.3″ | -6.4 |
| 600 yd | 2600 | 2400 | -52.9″ | -8.4 |
| 700 yd | 2508 | 2235 | -77.6″ | -10.6 |
| 800 yd | 2419 | 2078 | -107.8″ | -12.9 |
Point-mass G7/G1 drag model, standard atmosphere — within ~2% of reference solvers to 1000 yd; real barrels and conditions vary. Open in Ballistic Compare →
Performance
Dimensionscase measurements · scale drawing · size vs familiar rounds
Case dimensions — the scale drawing at the top of the page is built from these.
SAAMI · approximate| Measure | mm | in | ✓ |
|---|---|---|---|
| Bullet ⌀ | 7.21 | 0.284 | · |
| Neck ⌀ | 8.05 | 0.317 | · |
| Shoulder ⌀ | 13.34 | 0.525 | · |
| Shoulder angle | 30° | — | · |
| Base ⌀ | 13.97 | 0.550 | · |
| Rim ⌀ | 13.56 | 0.534 | ~ |
| Belt ⌀ | n/a | ||
| Rim thickness | 1.27 | 0.050 | ~ |
| Neck length | 7.29 | 0.287 | ≈ |
| Case length | 72.39 | 2.850 | · |
| Overall length | 91.44 | 3.600 | · |
Size vs familiar rounds
Drawn at true 1:1 — every case is accurate relative to the others. Absolute size depends on your screen's pixel density, so measuring one against a real ruler may be off. 7mm Remington Ultra Magnum is highlighted below.
Factory loads
In production — 13 active loads across 7 brands. Top 1 shown · see all 13 →.
| Brand | Load | Grain | Bullet | FPS | ft·lb | BC |
|---|---|---|---|---|---|---|
| Nosler | Trophy Grade | 160 | AccuBond | 3,175 | 3,581 | 0.531 G1 |
Velocities are manufacturer-stated (test-barrel). Discontinued loads are shaded and marked.
Suitable powders
14 reloading powders listed for 7mm Remington Ultra Magnum, fastest to slowest. Cross-reference in the finder →
Reloading costestimate cost per round vs factory
Estimate your cost per round and how it compares to factory. Inputs are yours — nothing is stored.
Cost estimate only — not load data. Charge weight is your input; follow published manuals for safe charges.
Lineage
Connected reference
History
Introduced in 2001 as part of Remington's Ultra Magnum family, which also included .300 RUM and .338 RUM. The rebated rim allows use of a standard magnum bolt face despite the large case body. The 7mm RUM delivers impressive long-range ballistics but the brutal recoil and limited factory load selection have constrained its popularity.
FAQs
- What twist rate does 7mm Remington Ultra Magnum use?
- 7mm Remington Ultra Magnum typically uses a 1:9.5 twist rate.
- What bullet diameter is 7mm Remington Ultra Magnum?
- 7mm Remington Ultra Magnum uses a 0.284″ (7.214 mm) diameter bullet.
- Is 7mm Remington Ultra Magnum still in production?
- 7mm Remington Ultra Magnum is active; typical availability is limited.
- What is 7mm Remington Ultra Magnum used for?
- 7mm Remington Ultra Magnum is primarily used for hunting, long range.
- What is 7mm Remington Ultra Magnum based on?
- 7mm Remington Ultra Magnum is derived from the .404 Jeffery (rebased) case.
- What are the best powders for 7mm Remington Ultra Magnum?
- Reloading powders commonly listed for 7mm Remington Ultra Magnum include Norma 204, N560, Norma MRP, Vihtavuori N160, among 14 suitable options.
Sources & provenance
- Standard SAAMI — SAAMI cartridge & chamber drawing — 7mm Remington Ultra Magnum archived
- Standard SAAMI — ANSI/SAAMI Z299 — Cartridge & Chamber Drawings archived
Data & sources. Specs compiled from the Lindcott Armory reference; availability counted from 13 live factory loads; the trajectory is modeled (point-mass), not measured. See methodology. Spotted an error? Report it →
